Instruments

Microscopes:

JEOL 1230 (120 kV TEM)

Resolution, nm: 0.34
Filament: Tungsten
Voltage, kV: 40-120
Magnification: 80x-500 000x
Camera: Morada
(click to enlarge)

ThermoFisher (200 kV TEM)

accessable through Nalmin-platform/UiO)

TEM, electron tomography, STEM, STEM-tomo, cryo-EM, cryo-tomo

Resolution: 0.14 nm (TEM)
Filament: coldFEG
Voltage, kV: 80-200
Magnification: 600x-500 000x
Camera: Ceta 16M camera (4,096 x 4,096 CMOS)

FEI TALOS 200 kV TEM

High resolution for 3D insight. The Thermo Scientific™ Talos™ TEM is a powerful, versatile electron system for delivering 3D characterization of biological and biomaterials samples in cell biology, structural biology, and nanotechnology research.

The system's constant-power, C-Twin lens delivers outstanding optical performance to help ensure an optimal balance of contrast and resolution.

Resolution: 0.30 nm (TEM)
Filament: coldFEG
Voltage, kV: 20-200
Magnification: 600x-500 000x
Camera: Ceta CMOS 16M (4k x4k)

Location: DNR-J4021

Contact: 2278 1212



Microtomes and other equipment

Leica HPM 010 High-pressure freezer

A high pressure freezing system  for vitrifying samples up to 200µm in thickness.


Leica Freeze Substitution
Leica Ultracut UCT with Leica EM FCS (cryochamber for low temperature sectioning) (click to enlarge)
GFP-light source for microtome UCT
Leica Ultracut UCT (click to enlarge)
